LARGE All In One BUILD 70gal

Nice craftsmanship! I'll be following along on this one!



I know someone from Yoingstown. But I moved from. VA after living in Columbus when I was little.

Ok. I'll draw it up and send it to you in a pm.



I glued the chambers to the back of the tank. The black strips on the face of the chambers is a fix. I glued the strips to the side of the tank 1/2'' too deep. No big deal.
The white lines in the return area are for the pumps to set on.

The skimmer is from the 20 AIO I will run 2 of them untill I upgrade to the BH-1000



Remember me saying that the top bracing was going to be an issue. It runs right down the center of the skimmer chamber. I will cut it out and put one on each side of the chamber.



So it is time to glue up the false wall and build the overflow.

You can see the cut out for the overflow to the skimmer chamber

I drilled 1/4'' holes

Cut them on the bandsaw

ready for a bottom

ready to install

You can see the placement of the returns



Now that all the inside work is done I need to cover the ends of the tank were the false wall is and add some trim around the top and bottom of the tank.





OK I am ready for my first flow test.
Nov of 09 I was on a man made rock mission. Here are a couple I will use in this tank. They have had plenty of time to cure.



this is outstanding. I cant wait to see what this will look like set up



Thanks Blue,
I have to admit, It is running as I am typing. The best is yet to come. I had a couple of issues in the trouble shooting part of the tank. As with most things you build for the first time there is always something that will come up that you did not plan for. Stay tuned.



The stand was built Nov 09. Sorry no pick of the build. I used 3/4'' plywood for the sides, front,back, and doubled it up for the top. All sides are solid sheets with the openings cut out for the doors. The doors are plywood with an arch cut out and beadboard inserts. I lined everything with 1/4'' whiteboard. it will be easy to keep clean.
The tank will sit right next to the entry to the kitchen. There is a step up right at that point. I had to build a platform for the stand to sit on at the same height as the step. I made it so you can remove it if and when the tank is to be removed or relocated.
The blue tank in the stand is a freshwater holding tank for the ATO it holds 7 gal. I am hoping this will be enough to last a week.
The wife picked the color to match a wall in the dinningroom and I pick the gloss black to match the tank trim.



All I have to say is WOW just that Great build very nice job
